Repair Tips for Reel Readers
How to test and what to look for when doing your own repairs
When one of these goes bad you may see an error that would be 4x or 7x where x indicates thereel position, i.e. a 43 error code would indicate the reel reader on the third reel.
What is described below is for testing the reel reader card using this home built tester. The tester provides both a 50 volt source or a 5 volt source (switch selectable).
After describing this procedure I will tell you how to test the cards with out having to have a 50 volt source.
I designed and built a tester to make troubleshooting easier. I test the card and all of the photo-transistors
first, then I split the two halves of the card, one for cleaning but also so that I can use a dental tool, poking
it into the tiny opening to push the photo-transistor or IR Emitter back up and out of the small square opening. The photo-transistor/Emitter should be at something close to a 45 degree angle.
Once the bad components are pushed out of the way, I use my soldering iron to melt the solder on both leads at the same time while grasping the upper portion of the optic. It comes off very easily. Once removed use solder wick to remove the excess solder. You want to do this so that when you put in the new device the leads will be nearly flat on the PC board.
Replace the defective components and quickly tack one side, allow the solder to cool and then solder the other side. Once the other side has cooled you can go back and firmly solder the lead that was previously tacked. Reassemble and then retest to make sure that the optics are working properly. Tapping the top of the card lightly with the handle of a screw driver will show any intermittent connections.
The one question that may come up is what constitutes a bad device. Since the reader cards supply signals to TTL logic devices then we can use standard logic levels of 2.0 volts as a high and .8 volts as a low. When measuring the output of the photo transistor, if the voltage is less than 2.0 volts, while unblocked or higher than 0.8 volts when blocked then that photo-transistor (or emitter) is defective.
In the cards that I have repaired I typically see voltages of greater than 4 volts unblocked and .01 volts blocked for the 50 volt reader cards, 5 volt reader cards the unblocked voltage is 3.14 and the blocked voltage 0.2.
Test all of the emitters and photo-transistors first, the replace all defective ones. I make it a habit to clean the bulbs with alcohol on the 50 volt cards so that as much light as possible gets to the photo-transistor.
Testing reel readers without having a 50 volt source.
The 50 volt supply is only used to power the incandescent bulbs. They are in series along with the 470 ohm resistor. Each bulb requires 5 volts to operate properly.
You need a few basic items, a Volt/Ohm meter (DVM) , a 47K resistor, a light source (flashlight) and some clip leads and a 5 volt DC power supply
Split the cards by removing the 2 screws and lay the small card off to the side
If you lay the card flat on its back with the mounting bracket to the left then the pins at the bottom will number 1 through 16 from right to left
Measure the resistance between pin 16 and 14, Pin 16 is Vcc and 14 is Ground you should have a reading a bit above 500 ohms, indicating that the 470 ohm 2 W resistor and all of the bulbs are OK. If not in this range then you will have to remove the tape covering the backs of the bulbs and then measure resistance across each bulb individually. Remember the bulbs are wired in series like the old Christmas tree light strings.
Assuming that the bulbs and resistor are OK. Attach the ground lead of the volt meter and one end of the resistor to pin 14 (pairs 13/14)
of the card. Connect the other end of the resistor and the positive lead of the volt meter to pin 11.
Now using the 5 volt supply, apply 5 volts to pin 1 of the card and read the voltage, shine the light into the small (tiny) hole that is for Q1, voltage should be some where around 4.7 volts with the light on and some where less than 0.2 volts with the light off. Just keep in mind that ambient light might cause the light off reading to be higher. The acceptable voltage ranges need to be within the acceptable ranges used in ‘Logic” circuits so a logic high you need 2 volts or more and a logic low 0.8 volts or less.
You may find that if you have these readings, a Q-tip dipped into alcohol can be used to clean the top of the photo-transistor by pushing the Q-tip into the hole and then twisting the Q-tip. I routinely clean these as well as to clean the bulbs.
Repeat this process for each of the following pins 1, 3, 5, 7, 9
Other than pin 11, all of the other pins are in pairs
Pins 1 & 2 Collector of Q1
Pins 3 & 4 Collector of Q2
Pins 5 & 6 Collector of Q3
Pins 7 & 8 Collector of Q4
Pins 9 & 10 Collector of Q5
Pin 11, Common emitter
Pin 12 Missing (pin is cut off)
Pins 13 & 14 Ground
Pins 15 & 16 Vcc
This process is not nearly as quick or accurate as using the tester but should allow you to test each of the cards.
The 5 volt card testing process is not much different other than it is not necessary to split the cards and you need a 3K resistor instead of a 47K resistor.
Apply the 5 volts across pins 16 and 14 and then measure the voltage on the associated
pin pairs.
In this case the 3K resistor attached to pin 14 and pin 11 biases another transistor’s base (Q6), pulling it low so that it will turn on the IR Emitters. Remember to block the light for each IR emitter to see the photo-transistor transition to a low state.
Testing results for the 5 volt cards readers you will not read anywhere near 4.7 volts, they will be closer 3.0 volts for a high and about 0.2 volts for a low
Repair Tips for Power Supply
I have noticed that the schematic for the Bally E1000/E2000 power supplies list expected voltages, but, what does that mean?
I have a couple of these power supplies so I decided to do some testing to see what voltages were obtained under certain circumstances.
If you apply 12 VAC across pins 1 and 10 of the board J1 connector,you should be able to measure the voltages on the test points (+UR, ZC and 5V)
These voltage readings are based on a supply that has no load (nothing else connected)
UR = 15.96 VDC
ZC = 10.07 VDC
5v = 5.0 4VDC
One might think something is wrong because both UR and ZC are higher than the schematic states. However with no current we would expect to find the voltages higher, what matters is the voltage under load conditions.
Summit Systems Slot Machine Machines
The LM340-T5 Regulator has a maximum current output of 1 amp so using ohms law we know the voltage is 5 volts and the current is 1 Amp, Resistance can be calculated using the formula R=V/I (R=5/1) so R=5Ω, Now that we know what to use, we can figure out the wattage, this is rather simple, Watts = Amps x Volts so in this case we have 5 volts, 1 Amp so need 5 Watts. For testing I use a couple of 5Ω 5W resistors , actually, I use 20 Watt resistors to keep from burning my fingers. Anything smaller than 5W will burn and smoke is bad. The load resistors are placed across pins 13 and 20 of the J1 connector
To test the power supply drawing .5 amps we place 2, 5Ω resistors in series for a total of 10 Ω. With a 10 Ω load, drawing .5 amps these readings are fairly typical of what you should expect to see
UR = 12.16 VDC
ZC= 8.83 VDC
5v = 5.01 VDC
The final test is to test at full load, drawing 1 amp of current by removing one of the 5 ohm resistors so that only 5 ohms appears across pins 13 and 20 of J1, the readings you should expect to see would be.
UR = 7.57 VDC
ZC= 9.6 VDC
5v = 4.98 VDC
It would appear that the voltages shown on the schematic are voltages when the power
supply is measured with a full load.
I also recommend that when repairing these power supplies to remove the heat sinks from the bridge rectifier (BR1) and the 5 volt regulator (Q1). Clean off the old thermal heat sink compound and add new compound so that the heat transfer is more even. This will allow for maximum cooling.
The minimum voltage to expect from the LM340-T5 is 4.75 volts, if less than this then it is better to spend a couple of dollars and replace it.
Sometimes you will find that you have no voltage. In this case you want to check the 4 diodes and if the voltage seems to be half of what you expect then check the solder connections on the bottom side of the diodes. These will become bad because of heat. Other causes of no voltage is an open diode in the Bridge Rectifier (BR1).
I would recommend to anyone doing any type of repair work to invest in an ESR Meter. ESR means Equivalent Series Resistance and a high ESR can have adverse actions to your circuit. I have had several of these power supplies where despite changing the diodes, bridge rectifier and voltage regulator the output voltage was still below the regulators specified voltage of 4.75 volts @1 amp. These problems were resolved using my ESR meter and the discovery of the large 11,000 ufd capacitor having a high ESR value.
Can’t run Tests
I have seen many complaints of not being able to run the tests or clear errors on these E Series machines. If you have a light tower the WHITE light should be illuminated before the tests or resets can be done. This does not mean that a burnt out bulb will prevent this but only serves as a quick indication that you should be able to run tests or clear error codes. If you find that you are unable to run the tests or reset the machine, check the cherry switch behind the door hinges. If this switch goes bad it will signal the MPU board that the door is closed. Many owners of these E machines will bypass the door switch however the cherry switch must be operational
RAM Tester
Since many of the problems with the E Series slot machine are related to RAM failures I thought it would be a good idea to have one hanging around in my shop. I searched the web and located a guy that had developed a tester for testing the 6264 RAM chips. I sent him an email asking if this might be easily converted to test the 5101 RAM chip used in the Bally E Series slot machines and a large number of Bally Pinball machines. As it turned out he did not have a problem in making this modification as an ‘Engineering Change’ for me. My tester only tests the 5101 RAM chips, but NeoLoch Sales has since altered the design so that it will now test 5101, 6116, 21C14 and 9114 RAM Chips. It also will run on a 5, 12 volt power supplies or from a 9 volt battery.
For further information please visit his website NeoLoc the page will open in a new window. This tester is now obsolete and has been replaced by a newer more versatile version
Summit Systems Slot Machine Troubleshooting
If you have some electronic design work that you need to get done contact David, he is easy to work with and offers reasonable prices.
Summit Systems Slot Machine Maintenance
We only support Bally Machines that were converted by Summit Systems Inc. Please inquire about Summit Systems Slot Machine Parts. We do not support any other machine types. If you call looking for telephone support, I have to cover my time. It will be necessary to obtain credit card info to cover my time. The first 15 minutes are free. After that, $30 in 15 minute chunks.
Note: The coin out meter needs to be working near 100% for trouble shooting the electronics. This is because the coin out meter is used to display tilt codes relative to the failures.
Summit Systems Slot Machine Software
Reel Assembly Plugs: The two plugs at the back of the machine are notorious for making poor connection. Especially for low voltage circuits (coin out meter and the coin-in switch and more). If you see signs of oxidation on the pins, I recommend 'polishing' the pins with a Dremel tool and soft brass wire brush. Be careful not to wear off the tin plating. The brass under the tin plating oxidizes. So any exposed brass of the pins will shortly no longer make connection. After polishing the male pins, spray the female connectors with contact cleaner. Then insert and pull out the reel assembly 10-20 times which will help to 'wipe' some oxidation from the female pins. This process may need to be repeated (spray and insert) if poor connections are still noticeable.
Coin-Diverter: I recommend that the coin-diverter be disabled. The coin-diverter coil buzzes something terrible. If you cut the wire going to the coil and then tie back the armature so that coins are deflected into the hopper, then the buzzing stops and the machine works just fine.
Launch Switch: There is a switch on the lower left side of the reel assembly that has to toggle (actuate) as the reels are launched. The switch has a black and a green wire solder to in and plugs into the back of the main circuit board. This switch signals the slot controller board that the 'game has started'. The launch switch has an adjustment (the mounting plate moves). Also, the launch mechanism has an adjustment that set the trigger point of the launch. It the reels fail to spin (catch) the launce trigger will need adjustment (no power when launching the reels)
Hopper: Usually the hopper needs no maintenance. Maybe the coin-out switch and again those pesky connectors. There is an adjustment for the coin size at the rear of the lever with the roller. The coin-out switch should trigger about 2/3 of the way up the coin.
Coin Switches: The coin-in and the coin-out switches do go bad. If you have an ohmmeter, you can check the resistance of the switches as you activate them. The resistance should toggle from open (infinity) to closed very low resistance (less than 10 ohms). If the resistance changes without toggling the switch then the switch should be replaced.
Summit Systems Slot Machine Jackpots
Coin mechanism & coin accept coil: Once in a while the coin mechanism will need cleaning and lubrication. IF coins seam to stick now and then (not bent) try some contact cleaner on the moving parts. There is 'usually' a coil behind the coin mechanism). The coil pulls in an armature which allows coins to drop thru to the coin-in switch. This coil/armature is sometimes removed. The purpose of this mechanism is to prevent too many coins from being accepted. Also the 'coin lockout coil' is de-energized once the game has started and is only re-energized (to accept coins) when the game is complete. This mechanism us usually removed when an electronic coin mechanism has been installed in place of the mechanical coin mechanism.
Summit Systems Inc Slot Machines
***********************************************************************************************************************
Lubrication:
Reels: The reels need to spin freely and should free spin for at least 20 seconds (or longer). If you have to pull the reels off the axel for cleaning and lubricating the bearings, be sure to mark the reels with their position. Putting the reels back in the wrong order will make the game not work correctly (all 3 reels have symbols in different positions).
Stop mechanism: The stopping mechanisms should all react about the same. You can test by manually launching the reels and then depressing the reels stop solenoids. If any of the mechanism is sticky then the reel won't stop correctly and you will get a tilt.
Note: I have found that 'brake cleaner' works really well at dissolving sticky grease.
Note: On rare occasion is may be necessary to disassemble some parts of the mechanisms.
Summit Systems Slot Machine Repair Service
Note: WD-40 seems to work well for lubrication. Be careful not to get any WD-40 on the rubber piece inside the damper tube (white tube on the right side of the reel assembly). If the rubber part is sticky or melted, disassemble the damper mechanism, clean it thoroughly and re-assemble without the rubber part. That damper assembly prevents the handle for flying back when the handle is released when launching the reels.
